Materials: Polyester fiber.
Uses and Features: This product is specially designed for wastewater treatment plants as sludge dewatering mesh belt. It enjoys the features of air and water permeation, while not allowing the sludge. Due to its unique structure, the sludge will get easily off the belt after filtration. Easy cleaning and long service life.

Technical Index:

Model	Wire Drivemm		Gen-density/10cm		Air permeability m3/m2h	Net weight g/㎡	Use of
	Warp	Latitude	Warp	Latitude
WNW14803	0.7	0.8	142	60	3900	1400	And press sludge dewatering
WNW16803	0.7	0.8	156	50	6000	1400	Sludge, squeezing juice
WNW16904	0.75	0.9	156	47	8000	1800	Life of the steel industry sludge dewatering sludge
WNW121054	0.9	1.05	120	42	8000	1650	dewatering Iron and steel industry Sludge
WNW22903	0.5	0.9	220	50	9000	1200	Living sludge dewatering
WNW20703	0.5	0.7	200	70	10000	1000	Living sludge dewatering Chemical sludge dewatering
GW24504	0.5	0.5	240	130	8500	1180	Papermaking Network Paper sludge dewatering
WNW08903	0.9	0.9	78	50	8500	1430	Industrial sludge dewatering
WNW16704	0.7	0.7	160	90	120	1350	Building materials industries
WNW26908	0.5	0.9	26.4	69- 75	5000- 5500	1346	The viscosity The sludge dewatering
CZW12 Head	0.75	0.8	47	48		8500	Washing reticulum
